Weg Electric Motor 06036ET3E364TS-W22G, 60 Hp, 3600 Rpm, 364/5TS Frame, 230/460//380 Vac, TEFC, 3 PH, Foot-mounted W22 NEMA Premium Efficiency

WEG 06036ET3E364TS-W22G NEMA Premium Efficiency Motor is a reliable and efficient choice for your industrial automation and motion control needs. With a rated load of 230/460 and AC phase of three phase, this motor is capable of delivering high-quality performance.

The brand WEG is known for its superior quality and this motor is no exception. It is designed to provide reliable and efficient performance, making it an ideal choice for a wide range of applications. Whether you're looking for a motor for your industrial automation needs or simply need a reliable and efficient motor, this WEG Premium Efficiency Motor is an excellent choice.

06036ET3E364TS-W22G, 60 Hp, 3600 Rpm, 364/5TS Frame, 230/460//380 Vac, TEFC, 3 PH, Foot-mounted W22 NEMA Premium Efficiency.

Engineering Data

Standard NEMA MG-1 Frequency 60//50 Hz Voltage 230/460//380 V Number of poles 2 Degree of Protection IP55 Synchronous speed 3600 rpm Output rating 60 HP Mounting Foot-mounted Flange Without Mounting F-1 Terminal box¹ Left position Enclosure IC411 - TEFC

Frame 364/5TS Output 60 HP (45 kW) Number of Poles 2 Frequency 60 Hz Rated speed 3560 rpm Slip 1.11 % Rated voltage 230/460 V Rated current 134/67.0 A L. R. Amperes 884/442 A LRC 6.6x(Code G) No load current 30.0/15.0 A Rated torque 88.5 ft.lb Locked rotor torque 200 % Breakdown torque 260 % Locked rotor time 25s (cold) 14s (hot) Moment of inertia (J) 10.6 sq.ft.lb Design B Insulation Class F Service factor 1.25 Temperature rise 80 K Duty Cycle Cont.(S1) Starting Method Direct On Line Ambient temperature -20°C to +40°C Altitude 1000 m.a.s.l. Degree of Protection IP55 Enclosure IC411 - TEFC Mounting F-1 Rotation¹ Both (CW and CCW) Noise level² 79.0 dB(A)

I have 2 available. Call or Text Bob 435-440-3440
