229cc air-cooled OHV single-cylinder engine

Longitudinal engine layout

Swingarm rear suspension

Sporty MX-style graphics

Rubber-mounted engine Engine Type: Single-Cylinder Displacement: 14 cu. in. (229 cc) Bore x Stroke: Bore: 2.7 in. (68.5 mm); Stroke: 2.45 in. (62.2 mm) Cylinders: 1 Engine Cooling: Air Fuel System: Gas Starting System: Electric Front Suspension: Independent Double Wishbone Front Travel: 5.9 in. (149.9 mm) Front Brake Type: Dual Hydraulic Disc Front Tires: Maxxis® Razr Vantage: 22 x 7-10 Rear Suspension: Swing Arm Rear Travel: 5.7 in. (144.8 mm) Rear Brake Type: Sealed Drum Rear Tires: Maxxis® Razr Vantage: 22 x 10-9 Frame: Steel Fuel Capacity: 2.5 gal. (9.5 L) Ground Clearance: 5.7 in. (144.8 mm) Machine Dimensions (LxWxH): L: 68.5 in. (1739.9 mm); W: 41.8 in. (1061.7 mm); H: 42.6 in. (1082 mm) Wheelbase: 44.3 in. (1125.2 mm) Drive Train: Manual / Automatic Clutch
