ICA12-50JPLR 1/2" Corrugated Copper Plenum Rated Air Dielectric Coaxial Cable
17 Hours
43
1
$115.00
Description
Condition
Payment Types Accepted
Venmo
PayPalICA12-50JPLR 1/2" Corrugated Copper Plenum Rated Air Dielectric Coaxial Cable
50' - $115
100' - $140
250' - $525
500' - $980
2500' - $3950
FEATURES / BENEFITS
- Supports Multiple RF Signals
- Complete Shielding
- The solid outer conductor of the ClearFill®Line coaxial cable creates a continuous RFI/EMI shield that minimizes system interference.
- Outstanding Intermodulation Performance
- RFS Technologies coaxial cable's solid inner and outer conductors virtually eliminate intermods. Intermodulation performance is also confirmed with state-of-the-art equipment at the RFS Technologies factory.
- Wide Range of Applications
- Typical areas of application are feedlines for plenum-space installations within occupied buildings or structures.
Structure****Cable Type: Air-Dielectric, Corrugated Size: 1/2" Inner Conductor Diameter mm (in): 4.8 (0.19) Inner Conductor Material: Copper-Clad Aluminum Wire Dielectric Diameter mm (in): 11.8 (0.464) Dielectric Material: Extruded Polyethylene Outer Conductor Diameter mm (in): 13.8 (0.54)Outer Conductor Material: Corrugated CopperJacket Diameter mm (in): 15.93 (0.627)Jacket Material: PVC, Plenum Rated / Color RedWater-resistant
Testing and Environmental****Fire Performance: Flame Retardant, Plenum Rated Flame Retardant Jacket Specifications: Meets/Exceeds Steiner Tunnel Test Method UL 910, NEC 820-53 (a) CMP, NFPA-262. Regulatory Compliance: NEC Article 800 Communication Circuits ETL Listed to UL444Canadian CSA C.22.2/FT6Installation Temperature °C(°F): -20 to 60 (-4 to 140) Storage Temperature °C (°F): -40 to 85 (-40 to 185) Operation Temperature °C(°F): -40 to 85 (-40 to 185)
The ICA12-50JPLR 1/2" Corrugated Copper Plenum Rated Air Dielectric Coaxial Cable by RFS is a high-quality cable designed for wireless communication and HF defense applications. Made with solid copper-clad aluminum conductors and a water-resistant sheath color of red, this cable offers excellent resistance properties and an impedance of 50 Ω. Manufactured in the United States, this cable is ideal for use in various electrical equipment and supplies in the business and industrial sectors.
Call or Text
Bob
435-770-3440
