2022 Kawasaki - Teryx S LE

(MILES 2788)

POWER Engine 4-stroke, SOHC, 4-valve V-twin, liquid-cooled Displacement 783cc Maximum Torque 47.0 lb-ft@ 5500 rpm Bore x Stroke 85.0 x 69.0mm Compression Ratio 10.7:1 Fuel System DFI® with two 36mm Mikuni throttle bodies Ignition TCBI with electronic advance Starting System Electric Transmission Automatic CVT with centrifugal clutch (H,L,N,R) Final Drive Selectable 2WD/4WD with locking front differential, shaft Engine Braking Yes CAPABILITY Front Suspension / Wheel Travel Double Wishbone; Fox Podium coil-over shocks with piggyback reservoir, adjustable preload and 24-way compression damping/8.0 in. Rear Suspension / Wheel Travel Double Wishbone; Fox Podium coil-over shocks with piggyback reservoir, adjustable preload and 24-way compression damping/8.3 in. Front Tires Maxxis 26 x 9-12 Rear Tires Maxxis 26 x 11-12 Steering Electric Power Steering (EPS) / rack-and-pinion Front Brakes Dual hydraulic discs with two-piston calipers Rear Brakes Sealed, oil-bathed, multi-disc Ground Clearance 11.2 in Fuel Capacity 7.9 gal Turning Radius 16.7 ft Cargo Bed Dimensions (LxWxH) 27.6 x 43.3 x 10.4 in Cargo Bed Load Capacity 600 lb Payload Capacity 1109 lb Seating Capacity 2 Towing Capacity 1300 lb Lighting (2) headlights, (2) taillights, stoplight DETAILS Frame Steel Tube Double-X Reinforcement Overall Length 118.1 in Overall Width 60.0 in Overall Height 75.8 in Curb Weight 1570.0 lb* Wheelbase 85.8 in Instruments Multi-function digital meter with speedometer, fuel gauge, clock, hour meter, odometer, dual trip meter and parking-brake indicator, R/N/P/4WD, water temp and low-oil-pressure indicators
