Yanmar SV08 - Mini Excavator

Weighing less than 1 ton, the excavators in this ultra-mini excavator can be smoothly operated and maneuvered in confined spaces. The excavator can easily enter through gates and through back alleys between residential buildings because of its compact design. Its true performance can be seen in various operations such as foundation work for residential buildings, structural alteration of buildings, laying water and sewer pipes, and landscaping

• Engine: Yanmar 2TE67L-BV/2TE67L-BV3 3-cylinder diesel, ~10.3 HP @ 2400-2800 rpm.
• Operating Weight: ~1,035 kg (2,348 lbs).
• Dimensions (Transport):
• Width (Tracks Retracted/Extended): 680 mm / 840 mm (2'3" / 2'9").
• Length: 4.01 ft (1.22 m).
• Height (Top of Cab/ROPS): 7.55 ft (2.3 m).

Performance:

• Max Digging Depth: 5 ft 4 in (1.6 m).
• Max Digging Force (Bucket): 2,360 lbs (10.5 kN).
• Max Digging Force (Arm): 1,390 lbs (6.2 kN).
• Travel Speed: 1.12 mph (1.8 km/h).
• Swing Speed: 8.4 rpm.
• Hydraulics: 2.6–2.8 gal/min (10-10.6 L/min) pump flow capacity.
• Fuel Capacity: 2.6–2.7 gal (10-10.2 L).
