Features:

Dual mono circuit designed by John Curl

Six line level inputs

Direct coupled -- no capacitors in signal path

Complementary hand matched MOSFET drive circuit

100% pure Class A circuitry, 44,000 µF power supply filter capacitance

Separate glass epoxy circuit boards for each channel

High current dual mono headphone circuit

Tiffany-style gold plated RCA jacks

Motorized volume control with LED indicator

Fully remote controlled, including input selection u External infrared remote input

Removable IEC AC cord

12 volt DC automatic turn-on trigger output

2 rack space mounting adapter available

Specifications:

Frequency Response: 5 Hz - 135 kHz, +0/-2 dB, full output; 5 Hz - 100 kHz, +0/-2 dB, full output -6 dB

Frequency Response: 5 Hz - 135 kHz, +0/-2 dB, full output; 5 Hz - 100 kHz, +0/-2 dB, full output -6 dB

Total Harmonic Distortion: 3⁄4 0.005%, 1 kHz; 3⁄4 0.007%, 20 kHz

IM Distortion: 3⁄4 0.004%

IM: unmeasurable

Maximum Output: > 10 V before clipping

Input impedance: 30 kOhms, ± 5%

Output impedance: 60 ohms

Recommended line load: 600 ohms

Recommended headphone: 8 ohms

Input Sensitivity: All inputs 150 mV, ±5%

Maximum Input Level: 10.5 V before clipping

S/N Ratio: > 102 dB, A-weighted, full output; 93 dB, A-weighted, full output -6 dB; > 84 dB, unweighted, full output; > 81 dB, unweighted, full output -6 dB

Maximum Hum: > 0.05 mV, full output; > 0.08 mV, full output -6 dB

Crosstalk: > 100 dB, < 10 kHz, full output; > 96 dB, 20 kHz, full output; > 90 dB, 20 kHz, full output -6 dB

Channel Balance: 3⁄4 0.3 dB; 3⁄4 1 dB, -60 dB

Dimensions: w 171/4" x h 3" x d 16", h 35/8" with feet

Weight: 16 lb.

Size: 6 x 10 x 5 inches

MSRP: $850
