Removed from club install. Four of the cabinets have eye hooks installed. $900 each or $10,000 for all 12 Selling a large amount of sound and lighting gear. Please check my other listings.
JBL VRX932LA Line Arrays at a Glance: Lightweight and built for smaller venues Great power handling and sound Flexible mounting options Lightweight and built for smaller venues The VRX932LA is a lightweight (48 lb.) compact 12" two-way line array speaker system designed for use in arrays of up to six units. VRX932LA is the ideal choice when line-array performance is needed but the venue size doesn't call for the very long-throw characteristics of larger line-arrays such as JBL's VerTec. The Constant Curvature waveguide mounts two compression drivers on a continuous arc. When additional VRX932LA speakers are added to the array the uninterrupted arc continues. In effect, all the drivers work together as if they were a single driver on a very long waveguide.
Great power handling and sound Since there are two HF drivers in each VRX932LA, the combined power handling and acoustic output of the system is far greater than a single driver could achieve. VRX932LA uses "amplitude shading" to shape the coverage of the array. Switches on the input plate allow, for example, the upper box in an array to reach the distant rear of a room while the lower box is shaded back to reduce excessive level at the front of the listening area.
Flexible mounting options One or two VRX932LAs may also be used on a tripod or over the VRX915S subwoofer. The integral rigging hardware is used to securely lock the array together. As many as six VRX932LA speaker systems may be suspended in a single array for a nominal vertical coverage of up to 90. Suspended applications require the JBL VRX932LA-SMAF array frame (available separately). For applications in which the array must be aimed sharply down, a second Array Frame may be installed to the bottom of the array serving as a pull-back.
JBL VRX932LA Line Arrays Features: Frequency Range (-10dB)1: 57Hz - 20kHz Frequency Response (+/-3dB)1: 75Hz - 20kHz Coverage Pattern: 100 x 15 nominal Crossover Modes: Bi-amp / passive, externally switchable Crossover Frequency: 1.2kHz Power Rating Passive: 800 W / 1600 W / 3200 W (Continuous/Program/Peak)2: Bi-amp LF: 800 W / 1600 W / 3200 W Bi-amp HF: 75 W / 150 W / 300 W LF Driver: 1 x JBL 2262H 12 in Differential Drive woofer with neodymium-magnet, dual voice-coils and magnetic gap. HF Driver: 3 x JBL 2407J, 1.0 in voice-coil, neodymium compression driver Nominal Impedance: Passive: 8 ohm Bi-amp LF: 8 ohms Bi-amp HF: 8 ohms Active Tunings: Tunings available at www.jblpro.com Enclosure: 18 mm, 11-ply birch plywood. Suspension / Mounting: Optional VRX-AF line array frame kit; M-10 Eyebolt Kit Finish: Black DuraFlex finish Grille: Powder coated, black, 16-gauge perforated steel with acoustically transparent foam Input Connectors: Neutrik Speakon NL-4 (x2) Dimensions (H x W x D): 13.75 in x 23.5 in x 15.0 in Net Weight: 48 lb
