420cc liquid-cooled longitudinally mounted single-cylinder four-stroke

Transmission

Five-speed with reverse

Front Suspension

Independent double-wishbone; 6.7-inch travel

Rear Suspension

Swingarm with single shock; 6.7-inch travel

Seat Height

33.7 inches

Warranty

Transferable, limited warranty. One year included. Engine Type: Single-Cylinder Displacement: 25.6 cu. in. (420 cc) Bore x Stroke: Bore: 3.41 in. (86.5 mm); Stroke: 2.82 in. (71.5 mm) Cylinders: 1 Engine Cooling: Liquid Fuel System: Gas Starting System: Electric Front Suspension: Independent Double Wishbone Front Travel: 6.7 in. (170 mm) Front Brake Type: Dual Hydraulic Disc Front Tires: Maxxis® 24 x 8-12 Rear Travel: 6.7 in. (170 mm) Rear Suspension: Swing Arm Rear Brake Type: Sealed Drum Rear Tires: Maxxis® 24 x 10-11 Frame: Steel Towing Capacity: 848 lb. (384.7 kg.) Fuel Capacity: 3.9 gal. (14.8 L) Ground Clearance: 7.1 in. (180.3 mm) Machine Dimensions (LxWxH): L: 82.8 in. (2103.1 mm); W: 47.4 in. (1204 mm); H: 46.2 in. (1173.5 mm) Wheelbase: 50 in. (1270 mm) Drive Train: Manual
