7 x 16 Horizon RDZ 18K Roll Off Trailer Trailer – Ready To Work!

The Horizon RDZ Series Roll-Off Dump Trailer (available in both Bumper Pull and Gooseneck configurations) is a commercial-grade, multi-purpose hauling ecosystem. Built around Horizon’s heavy-duty universal roll-off frame, the RDZ system allows contractors, waste management companies, and equipment operators to drop off multiple dumpster cans or flatbed attachments at various job sites using just one trailer.

Rather than utilizing a standard fixed dump box, the RDZ features a high-leverage hydraulic scissor hoist (or optional telescopic lift) paired with a heavy-duty 17,500 lb Winchmax winch. This setup allows the operator to effortlessly load, dump, and swap out 14-foot to 16-foot dump containers, flat decks, or concrete bins.

CORE FEATURES OF THE HORIZON RDZ ROLL-OFF SPEC

Universal Roll-Off Chassis Architecture

The main chassis is built on a massive 10-inch heavy-gauge I-Beam frame paired with a 2" x 3" x 7-gauge structural tubing bed frame.

• The Benefit: It provides exceptional torsional rigidity to prevent frame twisting when pulling heavy, off-center dumpster bins out of soft dirt or mud. Because it is a universal platform, it works seamlessly with all Horizon roll-off dumpster containers (EDZ series), flat decks, and specialized concrete bins without requiring modifications.

17,500 lb. Heavy-Duty Winchmax Electric Cable Winch

The winch setup at the nose of the tilt frame handles the heavy pulling power for container loading.

• The Benefit: Operating via an included wireless remote or wired controller, the 17.5K winch pulls fully loaded 12.5 to 16.5 cubic yard dump containers smoothly up the 58-degree tilt frame. The high weight rating ensures you can pull heavy demolition debris, roofing shingles, or dirt-filled bins onto the frame without stalling the winch motor.

Dual-Action Hydraulic Scissor Hoist (51° Dump Angle)

Dumping functions are handled by a heavy-duty hydraulic scissor hoist powered by a KTI 12V hydraulic pump.

• The Benefit: When acting as a traditional dump trailer, the scissor hoist pushes the tilt frame up to a steep 51-degree dump angle. This aggressive angle breaks sticky clay, wet sand, or compacted trash loose instantly without requiring manual shoveling.

Heavy-Duty Running Gear Options (14K to 17.9K GVWR)

The RDZ comes standard with tandem 7,000 lb. axles and can be upgraded to dual 8,000 lb. axles with oil-bath hubs.

• The Benefit: Depending on your choice between Bumper Pull or Gooseneck and axle specs, the trailer offers a 14,000 lb. to 17,900 lb. GVWR. This provides net payload capacities ranging from 11,000 lbs to over 13,000 lbs, allowing you to haul maximum weight legally.

Mega Lockable Tongue Toolbox & Smart Charging Core

An oversized steel "Mega Toolbox" mounted on the front tongue houses all critical power components.

• The Benefit: Safely locked away from weather and theft are two Interstate 27 deep-cycle marine batteries, the KTI pump, and the winch assembly. Horizon includes a standard 110V integrated trickle charger (with an optional 10W roof-mounted solar panel) to keep your batteries constantly topped off between dumps.

5-Stage Powder Coat Finish in Multiple Custom Colors

The entire steel frame is blasted with steel grit before receiving an architectural-grade 5-step powder coat finish.

• The Benefit: Unlike standard paint that chips easily when roll-off container rollers contact the frame, Horizon’s baked-on powder coat creates a rock-hard armor shield. Available in distinct finishes like Midnight Black, Ash Grey, Military Green, and Flame Orange, it keeps your rental fleet looking professional.

THE HORIZON RDZ ROLL-OFF QUICK SPECS

• GVWR: 14,000 lbs to 17,900 lbs (depending on 7K vs. 8K axles and BP vs. GN setup).
• Payload Capacity: ~11,000 lbs to 13,200 lbs.
• Frame Sizes: Available in 14' and 16' Deck Lengths.
• Deck Height: Ultra-low 30-inch deck height.
• Winch: 17,500 lb. Winchmax Winch with Steel Cable & Wireless Remote.
• Tilt & Dump Angles: 58° Loading Angle / 51° Dump Angle.
• Axles: Dual 7,000 lb. or 8,000 lb. Dexter/Lippert Electric Brake Axles.

WHY A ROLL-OFF TRAILER OVER A STANDARD DUMP TRAILER?

• Multiple Job Sites with One Rig: Instead of buying three $15,000 dump trailers, you buy one RDZ roll-off trailer and three or four container bins. You can drop a bin at a roofing job, another at a yard cleanup site, and use the trailer frame to tow equipment in between.
• Ground-Level Loading Convenience: Standard dump trailers force workers to lift heavy debris over high 3-foot or 4-foot steel side walls. With a roll-off system, you roll the dumpster bin completely off onto the driveway or ground, allowing crews to walk debris straight in through the rear doors.
• Low Deck Height Equipment Hauling: With an optional flatbed attachment, the RDZ converts into an equipment hauler with an ultra-low loading angle, perfect for moving skid steers or mini-excavators.

IDEAL USERS FOR THIS TRAILER

The Horizon RDZ Roll-Off Trailer is the premier tool for Dumpster Rental Businesses, Roofing Contractors, Junk Removal Fleets, and General Demolition Companies. It is built strictly for operators who want to maximize business efficiency, lower fleet maintenance costs, and run an adaptable multi-container operation using a single, heavy-duty towing chassis.
