Engine

Engine Type 649cc liquid-cooled inline four-cylinder four-stroke

Bore And Stroke 67.0mm x 46.0mm

Compression Ratio 11.6:1

Valve Train DOHC; four valves per cylinder

Induction Programmed Fuel-Injection system (PGM-FI); 32mm throttle body

Drivetrain

Transmission Six-speed manual with Honda E-Clutch

Final Drive #525 Chain; 15T/42T

Chassis Suspension Brakes

Front Suspension 41mm inverted Showa® SFF-BP fork; 4.7-inch travel

Rear Suspension Single shock; 5.1-inch travel

Front Brake Dual 310mm discs with radial-mounted four-piston calipers; ABS

Rear Brake Single 240mm disc; ABS

Front Tire 120/70-17

Rear Tire 180/55-17

Dimensions

Rake 25.5°

Trail 4.0 inches

Wheelbase 57.0 inches

Seat Height 31.9 inches

Curb Weight 456 pounds (includes all standard equipment, required fluids and a full tank of fuel)

Fuel Capacity 4.1 gallons

Other

Model ID CB650RAC

Emissions Meets current EPA standards. Models sold in California meet current CARB standards and may differ slightly due to emissions equipment.

Available Colors Matte Black Metallic Engine Type: In-Line Displacement: 39.6 cu. in. (649 cc) Bore and Stroke: Bore: 2.64 in. (67 mm); Stroke: 1.81 in. (46 mm) Cooling: Liquid Compression Ratio: 11.6:1 Fuel System: Gas Transmission: Manual Front Suspension: Inverted Fork Rear Suspension: Twin Sided Swing Arm Front Brakes: Dual Hydraulic Disc Rear Brakes: Hydraulic Disc Front Tire: Metzeler Roadtec 01: 120/70ZR 17 (58W) Rear Tire: Metzeler Roadtec 01: 180/55ZR 17 (73W) Wheelbase: 57 in. (1447.8 mm) Seat Height: 31.9 in. (810.3 mm) Rake: 25.5 Trail: 4 in. (101 mm) Fuel Capacity: 4.1 gal. (15.5 L) Speedometer: Standard Tachometer: Standard Odometer: Standard
