Specifications:

Power and output Rated Input Voltage: 208/230V or 460V (three-phase)

Rated Output Current: 400ADuty Cycle: 60% at 400A (DC), 50% at 400A

(Pulse)Output Range: 30-400A

Physical specifications Dimensions: (395 X 710 X 810 mm) (15.6 X 28.0 X 31.9 inches)

Mass: Approximately 80-84 kg (176-185 lbs)

Welding capabilities Processes: Advanced MIG, MIG, HD MIG, Flux-cored, and air carbon arcMetal Types: Mild steel, stainless steel, and aluminum

Advanced Functions: SmartPulse welding for automatic waveform WavePulse for optimized pulse welding

Constant Penetration mode Built-in interface for robotic integration Data and Control: USB port for data logging Optional tablet communication kit for remote control and monitoring Ability to load and save up to 100 welding jobs
