Specifications:

Number of Rolls 4

Bending Length (L) 10' 2"

Pre-bending Capacity 25/32"

Bending Capacity 1"

Top Roll Diameter 15.75"

Bottom Roll Diameter 14.57"

Side Rolls Diameter 11.81"

Max. Pass-Through 2-1/2"

Working Height (C) 58.66"

Length (U) 237"

Width (G) 83"

Height (Y) 75"

Weight (Approx.) 47,000 lbs.

Motor Power 30 HP

Power Supply 460V / 3 Phase / 60 Hz (or Request)

Bending Speed Dual Speed

Feeding Rolls 2 Independent planetary gear boxes and hydraulic motors Roll Housing Spherical roller bearings and bronze housings

Roll Material High tensile carbon steel C45

Roll Hardening Induction hardened 54±2 HRc

Roll Positioning Proportional speed electronic synchronous

Roll Calibration Automatic

Control Unit DRO

Conical Bending Conical bending device standard

Lubrication Manual and automatic
