• Model / Series: Fox 32 FLOAT 29 (Factory or Evolution series; FIT cartridge damper) • Wheel Size: 29” • Travel: 120 mm • Stanchions: 32 mm aluminum, Kashima-coated uppers (on Factory versions; hard anodized on Evolution) • Damper: FIT (Fox Internal Technology) RLC cartridge\

• Rebound damping adjustment (external knob at the bottom of the right leg)\
• Low-speed compression adjustment\
• Lever-actuated lockout (on-the-fly, with adjustable lockout force on some versions)\

• Spring: Air (Schrader valve on top of left leg for pressure adjustment; volume spacers possible) • Steerer Tube: 1.5” tapered (1.5” lower / 1-1/8” upper), aluminum • Axle / Hub Compatibility: 15 mm thru-axle QR (most common on these) or 9 mm quick-release, 100 mm spacing; post-mount disc brake • Rake / Offset: 51 mm (standard for the era’s 29er geometry) • Weight: ≈ 1.65–1.85 kg / 3.6–4.1 lbs (complete fork, depending on exact axle and finish) • Intended Use: XC / trail • Other Details:\

• Lightweight magnesium lowers\
• Air spring with positive/negative chambers
