Halo L855PX Specifications

$10 each. Make me an offer?

Physical Dimensions Measurement Value Diameter 5¼ inches Length 6¾ inches Max Extension 9⅞ inches Finish Baked-enamel satin white Electrical Ratings Parameter Specification Compatible Track Halo Power-Trac system Lamp Type Single PAR38 Max Wattage 150W Voltage 120V (line-voltage) Certifications UL & CSA approved System Compatibility

POWER-TRAC SYSTEM INFO The L855PX works specifically with Halo Power-Trac systems, which are two-circuit capable tracks. It will NOT fit standard H-type (3-wire) or J-type tracks — the Power-Trac connector has a unique configuration. Track System Compatible? Halo Power-Trac Yes (designed for this) Standard H-Type (Halo) No — different connector Lazer-by-Halo ️ Some models work, check adapter J-Type / L-Type No — incompatible Key Features

Feature Benefit PAR38 Socket Handles larger flood/spot bulbs for wide coverage 150W Capacity Bright output for accent/task lighting Satin White Finish Blends with most ceilings/walls UL/CSA Listed Safe for residential/commercial use Quick-Mount Adapter Attaches anywhere along track without tools Typical Applications

Use Case Why It Works Kitchen island lighting PAR38 throws wide, powerful light Retail displays Adjustable aim, high lumens Gallery/art accent Precision beam control Living room general lighting Multiple units cover large areas Installation Notes for Your Projects

INSTALLATION TIP INFO Power-Trac uses a 2-circuit system that allows independent switching of fixtures on the same track. You'll need to wire the track feed to match your switch configuration before mounting fixtures. Track lengths available: 4', 8', 12' (extruded aluminum channel) Finishes on track: White (P) or Black (MB) Rotation: Typically ~330° horizontal, 0-90° vertical pivot Bulb recommendation: LED PAR38 equivalents (15-20W LED ≈ 150W halogen brightness) Comparison to Other Halo Models

Model Lamp Type Max Wattage Size L855PX PAR38 150W 5¼" dia × 6¾" L725PX R14 25W Smaller L2771 MR16/PAR series 150W Flatback cylinder Since you're a handyman, a few practical notes:

LED retrofit: You can swap the PAR38 bulb for an LED equivalent to save energy while keeping the fixture Track feed: Make sure your junction box feeds match Power-Trac's two-circuit requirements if you want switched zones Replacement parts: Connectors, adapters, and ends are readily available at electrical supply houses Need info on wiring diagrams, compatible LED bulbs, or track accessories for the Power-Trac system?
